Thin rectangular E3.S enterprise SSD with silver metal casing and gold edge connector

Solidigm

Solidigm D5-P5336 7.68TB E3.S 7.5mm PCIe 4.0 enterprise SSD SBFPFABV076TOP1

SKU CH-6WRW-13AWN MPN SBFPFABV076TOP1

E3.S 7.5mm PCIe 4.0 enterprise SSD with 7.68TB QLC NAND, 6800 MBps read, 1800 MBps write and 0.42 DWPD endurance

  • Form FactorE3.S 7.5mm
  • Capacity7.68TB
  • Memory Components192 L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 6800 MBps
  • Max Sequential WriteUp to 1800 MBps

Option 7.68TB E3.S Opal

Show 21 more configurations

Struck-through versions exist but are not stocked here.

  • 68TB capacity supports massive read-heavy datasets
  • Up to 6800 MBps sequential read accelerates data access
  • 770000 random read IOPS handles heavy concurrent workloads
  • 42 DWPD endurance rated for 5.92 PBW total writes
  • 2,000,000 hours MTBF ensures long-term reliability

Solidigm D5-P5336 7.68TB E3.S enterprise SSD

The Solidigm D5-P5336 is a 7.68TB enterprise solid-state drive built for read-intensive data-centre workloads. It uses an E3.S 7.5mm form factor and connects via a PCI-Express 4.0 x4 interface. The drive targets storage arrays and servers that prioritise capacity and power efficiency over write endurance.

PCIe 4.0 sequential read up to 6800 MBps

The headline specification is a maximum sequential read speed of up to 6800 MBps across the PCIe 4.0 link. Sequential write reaches up to 1800 MBps while 4KB random read delivers 770000 IOPS at QD256. Endurance is rated at .42 DWPD with 5.92 PBW total bytes written.

E3.S 7.5mm form factor fits dense server chassis

The 7.5mm E3.S module slides into hot-plug bays designed for high-density platforms, drawing 5W idle and 15W active. Opal security is supported for hardware-based encryption. Operating temperature spans 0°C to 70°C with shock resistance of 1000 G at .5 msec. It is not suited for write-heavy logging or applications that exceed the rated endurance.

Highlights

  • 68TB capacity supports massive read-heavy datasets
  • Up to 6800 MBps sequential read accelerates data access
  • 770000 random read IOPS handles heavy concurrent workloads
  • 42 DWPD endurance rated for 5.92 PBW total writes
  • 2,000,000 hours MTBF ensures long-term reliability

Specifications

BrandSolidigm
ModelD5-P5336
Part NumberSBFPFABV076TOP1
Form FactorE3.S 7.5mm
Capacity7.68TB
Memory Components192 L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 6800 MBps
Max Sequential WriteUp to 1800 MBps
4KB Random Read770000 IOPS (4K, QD256)
4KB Random Write17900 IOPS (16K, QD256)
Endurance0.42 DWPD (16K RW) / 5.92 PBW
MTBF2,000,000 hours
SecurityOpal
Power Consumption (Idle)5W
Power Consumption (Active)15W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight90g +/- 10g
Shipping weight0.17 kg
Package size140 × 110 × 17 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the 6800 MBps sequential read mean once the drive is installed in a server?

The drive can sustain up to 6800 MBps sequential read at the PCIe 4.0 x4 interface when the workload matches the rated queue depth and block size.

How does the PCIe 4.0 x4 interface cap real-world throughput?

PCIe 4.0 x4 provides a theoretical ceiling near 8 GBps, so the drive's 6800 MBps read and 1800 MBps write operate within that limit.

What physical slot and clearance does the E3.S 7.5mm form factor require?

It fits an E3.S 7.5mm hot-plug bay and needs a backplane or cage that accepts the 7.5 mm z-height and the standard E3.S connector.
