Rectangular green circuit board with gold edge connector, silver label, black controller chips, 7.5mm thick

Solidigm

Solidigm D5-P5336 SBFPFABV307T001 30.72TB E3.S 7.5mm enterprise SSD

SKU CH-KVQ1-V4ZNX MPN SBFPFABV307T001

E3.S 7.5mm PCIe 4.0 drive holds 30.72 TB with 192-layer QLC NAND and 0.56 DWPD endurance

  • Form FactorE3.S 7.5mm
  • Capacity30.72TB
  • Memory Components192 L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 7000 MBps
  • Max Sequential WriteUp to 3000 MBps

Option 30.72TB E3.S

Show 21 more configurations

Struck-through versions exist but are not stocked here.

  • Massive 30.72TB capacity fits dense storage racks
  • PCIe 4.0 x4 delivers up to 7000 MB/s sequential reads
  • 192-layer QLC 3D NAND enables high capacity in E3.S 7.5mm form
  • 56 DWPD endurance rated for 31.55 PB written
  • 2M-hour MTBF supports continuous data-centre operation

Capacity and form factor

The Solidigm D5-P5336 is a 30.72TB enterprise solid-state drive in the E3.S 7.5mm form factor. It uses 192-layer QLC 3D NAND and connects through a PCI-Express 4.0 x4 interface. The drive is new and intended for internal server and data-centre installations.

Read-intensive workloads

This drive suits read-heavy applications such as content delivery, analytics and warm-tier storage where its 7000 MBps sequential read and 1005000 IOPS random read provide high throughput. The 0.56 DWPD endurance rating and 31.55 PBW total write budget make it a poor fit for write-intensive databases, logging or caching tiers that exceed those limits.

Power and thermal envelope

Idle power is 5W and active power reaches 23W, so the platform must supply adequate cooling within the 0°C to 70°C operating range. The E3.S 7.5mm slot frees vertical space compared with taller modules, while the 90g weight adds minimal load. Shock tolerance of 1000 G and vibration ratings of 2.17 GRMS operating and 3.13 GRMS non-operating help the drive survive dense rack environments.

Highlights

  • Massive 30.72TB capacity fits dense storage racks
  • PCIe 4.0 x4 delivers up to 7000 MB/s sequential reads
  • 192-layer QLC 3D NAND enables high capacity in E3.S 7.5mm form
  • 56 DWPD endurance rated for 31.55 PB written
  • 2M-hour MTBF supports continuous data-centre operation

Specifications

BrandSolidigm
ModelD5-P5336
Part NumberSBFPFABV307T001
Form FactorE3.S 7.5mm
Capacity30.72TB
Memory Components192 L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random Read1005000 IOPS (4K, QD256)
4KB Random Write39200 IOPS (16K, QD256)
Endurance0.56 DWPD (16K RW) / 31.55 PBW
MTBF2,000,000 hours
Power Consumption (Idle)5W
Power Consumption (Active)23W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight90g +/- 10g
Shipping weight0.17 kg
Package size140 × 110 × 17 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does my server need an E3.S 7.5mm drive bay to install this SSD?

Yes, the drive uses the E3.S 7.5mm form factor and requires a compatible hot-plug bay or backplane that accepts that exact size.

Will the PCIe 4.0 x4 interface run at full speed on my older PCIe 3.0 backplane?

The drive is backward compatible with PCIe 3.0 slots, but sequential reads up to 7000 MBps and writes up to 3000 MBps will be limited to the 3.0 bus ceiling.

How can I confirm the drive is delivering the rated 1005000 IOPS random read performance after installation?

Run a 4K random read test at queue depth 256 using a tool such as FIO or CrystalDiskMark and compare the result to the 1005000 IOPS specification.
