Thin rectangular E3.S 7.5mm SSD with label, gold edge connector visible

Solidigm

Solidigm D5-P5336 7.68TB E3.S 7.5mm PCIe 4.0 enterprise SSD SBFPFABV076TOF1

SKU CH-Z2GY-6VQDF MPN SBFPFABV076TOF1

E3.S 7.5mm enterprise SSD with 7.68TB QLC 3D NAND, PCIe 4.0 x4, 6800 MB/s read, 1800 MB/s write, 770000 IOPS random read, FIPS security, 0.42 DWPD endurance

  • Form FactorE3.S 7.5mm
  • Capacity7.68TB
  • Memory Components192 L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 6800 MBps
  • Max Sequential WriteUp to 1800 MBps

Option 7.68TB E3.S FIPS

Show 21 more configurations

Struck-through versions exist but are not stocked here.

  • High-capacity 7.68TB storage for dense server deployments
  • PCIe 4.0 interface delivers up to 6800 MBps sequential read speed
  • 770000 IOPS random read accelerates data-intensive workloads
  • FIPS-certified security protects sensitive enterprise data
  • 2000000-hour MTBF ensures long-term reliability in data centres

Enterprise capacity and form factor

The Solidigm D5-P5336 is a 7.68TB enterprise SSD built in the E3.S 7.5mm form factor. It uses 192-layer QLC 3D NAND and connects through a PCIe 4.0 x4 interface. The drive is new and carries FIPS security certification for regulated environments.

Read-optimised workloads

This drive suits read-heavy applications such as content delivery, analytics and warm data tiers where its 6800 MBps sequential read and 770000 IOPS random read deliver throughput. The 0.42 DWPD endurance rating and 1800 MBps sequential write make it a poor fit for write-intensive databases, logging or high-frequency checkpointing. Buyers who need sustained heavy write cycles should consider drives with higher endurance specifications.

PCIe 4.0 x4 interface requirement

The single specification that decides fit is the PCIe 4.0 x4 electrical and physical interface. The host backplane or riser must provide an E3.S 7.5mm slot wired for PCIe 4.0 x4; a PCIe 3.0-only or x2-wired slot will limit performance and may prevent operation.

Highlights

  • High-capacity 7.68TB storage for dense server deployments
  • PCIe 4.0 interface delivers up to 6800 MBps sequential read speed
  • 770000 IOPS random read accelerates data-intensive workloads
  • FIPS-certified security protects sensitive enterprise data
  • 2000000-hour MTBF ensures long-term reliability in data centres

Specifications

BrandSolidigm
ModelD5-P5336
Part NumberSBFPFABV076TOF1
Form FactorE3.S 7.5mm
Capacity7.68TB
Memory Components192 L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 6800 MBps
Max Sequential WriteUp to 1800 MBps
4KB Random Read770000 IOPS (4K, QD256)
4KB Random Write17900 IOPS (16K, QD256)
Endurance0.42 DWPD (16K RW) / 5.92 PBW
MTBF2,000,000 hours
SecurityFIPS
Power Consumption (Idle)5W
Power Consumption (Active)15W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight90g +/- 10g
Shipping weight0.17 kg
Package size140 × 110 × 17 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much data can I write before the 7.68TB D5-P5336 reaches its rated endurance limit?

The drive is rated for 5.92 PBW, which equals 0.42 DWPD over its warranty period using 16K random write workloads.

What is the steady-state power draw and temperature range when this E3.S drive runs continuously?

Active power is 15W, idle power is 5W, and the operating temperature range is 0°C to 70°C.

Which server slot and connector standard does the E3.S 7.5mm form factor require?

It requires an E3.S 7.5mm backplane slot with a PCI-Express 4.0 x4 electrical interface.
